TL2000 2 tons telescopic boom loader
TL2000 2 tons telescopic boom loader specification,
1.0 Engine Details
(1) Model: YUNNEI Turbocharged Engine
(2) Engine Type:In-line arrangement, water-cooled, four-cycle diesel Engine
(3) Rated Power: 65KW
(4) Rated Speed: 2400 r/p.min (rpm)
(5)Optional Engine:YUNNEI engine(55KW/60KW),YUCHAI engine(58KW/62KW),
WEICHAI engine(53KW/56KW/65KW),IMPORT YANMAR EPA engine(KW)
2.0 Transmission System
Hydraulic converter + gearbox+drive shaft + hub reduction axles
3.0 Bucket
(1) Bucket Capacity: 1m³
(2) Bucket width: 1900mm
(3) Bucket type:Heavy-duty bolt on teeth
(5) Rated Load: 2000kg including attachment or bucket
4.0 Overall Dimensions
(1) Overall Length: 6600mm
(2) Overall Height:2750mm
(3) Overall Width: 2050mm
(4) Max. lifting Height:5000mm
(5) Lifting to bucket hinge pin Height:4500mm
(6) Bucket Unloading Height:3950mm
(7) Unloading Distance: 1950mm(Arm extended)
1150mm(Arms recovered)
5.0 Operating Specifications
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 4600mm(The right front wheel)
Min Turning Radius: 2300mm(The left rear wheel)
(3) Driving System: Hydraulic converter, four wheel drive
(4) Hydraulic joystick control.
6.0 Brake System
(1) Service Brake:Safer air assist disc brake braking system
(2) Parking Brake:Hand operated（Disc brakes）
7.0 Tire
(1) Model:16/70-20 (2)Width: 380mm(3) Diameter: 1075mm
(2) Optional Model:16/70-20 Herringbone tire
8.0 Wheelbase: 2500mm
9.0 Track: 1600mm
10.System pressure: 20Mpa; Hydraulic output:96L/min
11.Machine weight: 5800KG
